撥動開關主要技術參數(shù)/Slide Switch Main data
|
|
1.使用功率/額定值Rating
|
DC 50V 0.3A~1A
|
|
2.觸點電阻/Contact Resistance
|
< 100 mΩ
|
|
3.絕緣電阻/Insulation Resistance
|
≥ 100 MΩ
|
|
4.耐壓/Withstand Voltage
|
500V AC for 1 minute
|
|
5.撥動力/Operating Force
|
180~500gf
|
|
6.使用壽命/Life cycles
|
10000次
|
|
7.操作溫度/Operationg Temperature
|
-16℃to+60℃
|
|
8.儲存溫度/Storage Temperature
|
-40℃to+85℃
|
|
9.符合標準/Complies with
|
RoHs&Reach
|
